Multibeam Antenna Matrix



Frequency (MHz)

H-Beam

Type

Model

Patterns

Bracket

Gain (dBi)

V-Beam °

L x W x D (inches)

698-896

22°

3 beam Xpol

X7C-TB-622

Download

919032

19.8

12.2

72 x 36 x 10.75

1710-2170

11°

6 beam Xpol

XAP-HB-311

Download

919058

20.8

10

36.0 x 36.0 x 8.9

1710-2170

22°

3 beam Xpol

XAP-TB-322

Download

919058

20.8

10.5

36.0 x 18.0 x 6.9

698-960 &1695-2700

34°

2 beam Xpol

XGU-MB-134

Download

919050

10.0 & 10.5

60° & 60°

14.6 x 24.3 x 7.1



Antenna brackets and mounting hardware

919011

BRACKET KIT, INSTALLATION,  2-POINT, 12 DEG D-TILT

919032

BRACKET KIT, INSTALLATION,  3-POINT, 6 DEG D-TILT

919046

BRACKET KIT, INSTALLATION,  2-POINT, 9 DEG D-TILT

919050

BRACKET KIT, INSTALLATION,  VENUE ANTENNA

919058

BRACKET KIT, INSTALLATION,  2-POINT, 6 DEG D-TILT



Installation guide

81900510

Venue Bracket Antenna Installation Guide for 919050 and 919055 bracket kits
